Septic Tank Dimensions

I = invert - measured from the bottom of the tank to the bottom of the inlet. LP = Low Profile

SEPTIC TANKS


500 GALLON 1 PIECE              I=48" W=53" L=68" TH=59 1/2"

1000 GALLON 1 PIECE            I=48" W=5'8" L=8'2" TH=60"

1000 GALLON 1 PIECE LP      I=41" W=5'8" L=8'2" TH=52"

1000 GALLON 2 PIECE            I=60" W=5'4" L=8'4" TH=6'

1250 GALLON 1 PIECE LP      I=41" W=68" L=147" TH=52"

1250 GALLON 2 PIECE            I=60" W=59" L=9'3" TH=72"

1500 GALLON 1 PIECE            I=48" W=68" L=147" TH=60"

1500 GALLON 2 PIECE            I=58" W=6'1" L=9'2" TH=72"

2000 GALLON 2 PIECE            I=60" W=7' L=12'9" TH=70"

3000 GALLON 3 PIECE            I=88" W=7' L=12'9" TH=99"


DRYWELLS

(Height x Diameter)


3'X6' HONEYCOMB 650 GALLON   (INCLUDES COVER)

4'X4' 300 GALLON

4'X6' 850 GALLON

4'X8' 1500 GALLON
